• SKF KMT30 Precision Lock Nut with Locking Pins M150x2mm
1 1

SKU: KMT30-SKF

SKF KMT30 Precision Lock Nut with Locking Pins M150x2mm

SKF KMT30 Precision Lock Nut with Locking Pins M150x2mm
$483.41 ex VAT
$483.41 ex VAT
Sale Sold out

In stock

Price Break
10+ $323.80
19+ $305.61
29+ $301.97
39+ $298.33
49+ $294.69
74+ $291.06
99+ $272.86
199+ $269.23
249+ $265.59
499+ $261.95
999+ $254.67

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMT Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation and a chamfered front face for ease of access to the radial locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M150x2
Technical
d1 172mm
d2 185mm
d3 174mm
d4 152mm
B 32mm
b 14mm
h 6mm
Axial load capacity 1040 kN
Loosening torque 1440 Nm
Weight 1.95 kg
G M150x2
Spanner TMFN23-30
Grub screw M10
Screw torque 35 Nm
