SKU: LFTC30EC-RHP
RHP LFTC30EC Two Bolt Oval Cast Iron Flange Housing Bearing 30mm Bore
RHP LFTC30EC Two Bolt Oval Cast Iron Flange Housing Bearing 30mm Bore
Regular price
$63.13
ex VAT
Regular price
Sale price
$63.13
ex VAT
In stock
Price Break
10+
$42.28
20+
$39.91
30+
$39.43
40+
$38.96
50+
$38.48
75+
$38.01
100+
$35.63
200+
$35.16
250+
$34.68
500+
$34.21
1000+
$33.26
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
RHP LFTC EC Series 2 Bolt Oval Cast Iron Housing Units: Two bolt oval cast iron bearing unit supplied with a sealed flat back bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar and grub screw to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 30mm
- Style:
- LFTC
- Bolt Hole Centres:
- 90.5mm
Technical
Technical
| Bore | 30mm |
|---|---|
| L | 84mm |
| H | 112mm |
| J | 90.5mm |
| G | 10mm |
| A | 20.5mm |
| A2 | 38.07mm |
| B2 | 35.68mm |
| s1 | 9.04mm |
| d2 | 44.45mm |
| Dynamic load | 19500 N |
| Static load | 11300 N |
| Rec max speed | 5300 rpm |
| Weight | 0.8 kg |
| Insert | <a href="advanced_search_result.php?keywords=1230-30ECG+insonly">1230-30ECG Click Here</a> |
| Casting group | 4 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
