SKU: LM.16.UU.AJ.EU

LM16UUAJ Adjustable Linear Ball Bushing with Rubber Seals 16x28x37mm

LM16UUAJ Adjustable Linear Ball Bushing with Rubber Seals 16x28x37mm
$16.64 ex VAT
$16.64 ex VAT
Sale Sold out

Equivalent to: SM16GUUAJ LBD16UUAJ LB16NTYDD N16VUUADJ L16ADJUU TB16ADJUU

In stock

Price Break
3+ $11.14
5+ $10.52
10+ $10.39
15+ $10.27
20+ $10.14
30+ $10.02
40+ $9.39
50+ $9.26
60+ $9.14
75+ $9.01
100+ $8.76

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
16mm
Outside Diameter:
28mm
Length:
37mm
Technical
Inside Diameter dr 16mm Tol + 0 to - 6µm
Outside Diameter D 28mm Tol + 0 to - 12µm
Length L 37mm Tol + 0 to - 200µm
W 1.6mm
D1 27mm
h 1.5mm
Eccentricity 8µm
Dynamic load C 49 kgf
Static load C<sub>o</sub> 78 kgf
Weight 69 g
B 26.5mm Tol + 0 to - 200&micro;m
Number of ball rows 5
