SKU: LM.E.16.UU.AJ.EU

LME16UUAJ Adjustable Linear Ball Bushing with Rubber Seals 16x26x36mm

LME16UUAJ Adjustable Linear Ball Bushing with Rubber Seals 16x26x36mm
$16.58 ex VAT
$16.58 ex VAT
Sale Sold out

Equivalent to: KB16GUUAJ KBS1636PP MAM16ADJWW LBE16UUAJ

In stock

Price Break
3+ $11.10
5+ $10.48
10+ $10.36
15+ $10.23
20+ $10.11
30+ $9.98
40+ $9.36
50+ $9.23
60+ $9.11
75+ $8.98
100+ $8.73

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
16mm
Outside Diameter:
26mm
Length:
36mm
Technical
Inside Diameter dr 16mm Tol +9 to - 0µm
Outside Diameter D 26mm Tol + 0 to - 9µm
Length L 36mm Tol + 0 to - 200µm
W 1.3mm
D1 24.9mm
B 24.9mm
h 1.5mm
Eccentricity 12µm
Dynamic load C 49 kgf
Static load C<sub>o</sub> 78 kgf
Weight 57 g
Number of ball rows 4
Tolerances dr & D Apply to closed type only
