• LMEK16LUU Long Square Flanged Linear Ball Bushing with Rubber Seals and Resin Retainer 16x26x68mm
  • LMEK16LUU Long Square Flanged Linear Ball Bushing with Rubber Seals and Resin Retainer 16x26x68mm
  • LMEK16LUU Long Square Flanged Linear Ball Bushing with Rubber Seals and Resin Retainer 16x26x68mm
1 3

SKU: LMEK-16-L-UU-EU

LMEK16LUU Long Square Flanged Linear Ball Bushing with Rubber Seals and Resin Retainer 16x26x68mm

LMEK16LUU Long Square Flanged Linear Ball Bushing with Rubber Seals and Resin Retainer 16x26x68mm
$58.91 ex VAT
$58.91 ex VAT
Sale Sold out

In stock

Price Break
3+ $39.46
5+ $37.25
9+ $36.80
19+ $36.36
49+ $35.91
74+ $35.47
99+ $33.25
199+ $32.81
249+ $32.37
499+ $31.92
999+ $31.04

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
16mm
Outside Diameter:
26mm
Length:
68mm
Seals / Shields:
Rubber Sealed
Technical
Working Bore Diameter dr. 16mm
Bore Clearance +0.011/-0.001mm
D 26mm
D Clearance 0/-0.011mm
L 68mm
L Clearance 0/-0.3mm
D<sub>1</sub> 46mm
D<sub>1</sub> Clearance 0/-0.2mm
H 6mm
PCD 36mm
K 35mm
d<sub>1</sub> 4.5mm
d<sub>2</sub> 8mm
h 4.4mm
Squareness um 15
Basic Load Rating - Dynamic C 1230 N
Basic Load Rating - Static Co 2350 N
No of Ball Rows 5
