• LMK10UU Metric Square Flanged Linear Ball Bushing 10x19x29mm
  • LMK10UU Metric Square Flanged Linear Ball Bushing 10x19x29mm
  • LMK10UU Metric Square Flanged Linear Ball Bushing 10x19x29mm
1 3

SKU: LMK10.UU.EU

LMK10UU Metric Square Flanged Linear Ball Bushing 10x19x29mm

LMK10UU Metric Square Flanged Linear Ball Bushing 10x19x29mm
$17.67 ex VAT
$17.67 ex VAT
Sale Sold out

In stock

Price Break
3+ $11.83
5+ $11.17
9+ $11.04
19+ $10.90
49+ $10.77
74+ $10.64
99+ $9.97
199+ $9.84
249+ $9.71
499+ $9.57
999+ $9.31

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
10mm
Outside Diameter:
19mm
Length:
29mm
Seals / Shields:
Rubber Sealed
Technical
Ball Rows 4
dr 10mm
dr Tolerance 0 to -0.009mm
D 19mm
D Tolerance 0 to -0.013mm
L 29mm
L Tolerance 0 to -0.2mm
D1 39mm
D1 Tolerance 0 to -0.2mm
K 30mm
H 6mm
PCD 29mm
Mounting Hole 4.5x8x4.4mm
Basic Load Dynamic Rating C 373N
Basic Load Static Rating C0 549N
Mass 0.045g
Material Standard
Style Square Flanged
