• LMK25UU Metric Square Flanged Linear Ball Bushing 25x40x59mm
  • LMK25UU Metric Square Flanged Linear Ball Bushing 25x40x59mm
  • LMK25UU Metric Square Flanged Linear Ball Bushing 25x40x59mm
1 3

SKU: LMK25-UU

LMK25UU Metric Square Flanged Linear Ball Bushing 25x40x59mm

LMK25UU Metric Square Flanged Linear Ball Bushing 25x40x59mm
$24.16 ex VAT
$24.16 ex VAT
Sale Sold out

In stock

Price Break
3+ $16.18
5+ $15.27
9+ $15.09
19+ $14.91
49+ $14.73
74+ $14.55
99+ $13.64
199+ $13.45
249+ $13.27
499+ $13.09
999+ $12.73

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
25mm
Outside Diameter:
40mm
Length:
59mm
Seals / Shields:
Rubber Sealed
Technical
Ball Rows 6
dr 25mm
dr Tolerance 0 to -0.010mm
D 40mm
D Tolerance 0 to -0.016mm
L 59mm
L Tolerance 0 to -0.3mm
D1 62mm
D1 Tolerance 0 to -0.2mm
K 50mm
H 8mm
PCD 51mm
Mounting Hole 5.5x9.2x5.4mm
Basic Load Dynamic Rating C 980N
Basic Load Static Rating C0 1570N
Mass 0.27g
Material Standard
Style Square Flanged
