SKU: LMK6.UU.EU

LMK6UU Metric Square Flanged Linear Ball Bushing 6x12x19mm

LMK6UU Metric Square Flanged Linear Ball Bushing 6x12x19mm
$16.91 ex VAT
$16.91 ex VAT
Sale Sold out

In stock

Price Break
3+ $11.33
5+ $10.69
9+ $10.56
19+ $10.44
49+ $10.31
74+ $10.18
99+ $9.55
199+ $9.42
249+ $9.29
499+ $9.16
999+ $8.91

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
6mm
Outside Diameter:
12mm
Length:
19mm
Seals / Shields:
Rubber Sealed
Technical
Ball Rows 4
dr 6mm
dr Tolerance 0 to -0.009mm
D 12mm
D Tolerance 0 to -0.011mm
L 19mm
L Tolerance 0 to -0.2mm
D1 28mm
D1 Tolerance 0 to -0.2mm
K 22mm
H 5mm
PCD 20mm
Mounting Hole 3.4x6.5x3.3mm
Basic Load Dynamic Rating C 206N
Basic Load Static Rating C0 265N
Mass 0.017g
Material Standard
Style Square Flanged
