• NTN M-UCFC208D1 Metric Four Bolt Cast Iron Round Flanged Housing with 40mm Insert - Allow 2-3 Days
  • NTN
1 2

SKU: M-UCFC208D1-NTN

NTN M-UCFC208D1 Metric Four Bolt Cast Iron Round Flanged Housing with 40mm Insert - Allow 2-3 Days

NTN M-UCFC208D1 Metric Four Bolt Cast Iron Round Flanged Housing with 40mm Insert - Allow 2-3 Days
$52.76 ex VAT
$52.76 ex VAT
Sale Sold out

In stock

Price Break
3+ $35.34
4+ $33.36
9+ $32.96
19+ $32.56
49+ $32.17
99+ $31.77
499+ $29.78
999+ $29.39
1999+ $28.99
2999+ $28.59
4999+ $27.80

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
40mm
Style:
UCFC
Pitch Circle Diameter:
84.9mm
Technical
--- Dimensions
Shaft diameter 40mm
L 145mm
J 120mm
(J<sub>1</sub>) 84.9mm
A<sub>2</sub> 11mm
N 14mm
A<sub>3</sub> 10mm
A<sub>1</sub> 26mm
A 36mm
H<sub>3</sub> 100mm
A<sub>0</sub> 51.2mm
B 49.2mm
S 19mm
Fixing bolt M12
--- Load rating
Dynamic load C<sub>r</sub> 32.5 kN
Static load C<sub>0r</sub> 17.8 kN
Fatigue load limit C<sub>u</sub> 1.24 kN
--- Unit information
Mass 2 kg
