• RHP MFC100 Four Bolt Round Cast Iron Flanged Bearing Unit and 100mm Insert
1 1

SKU: MFC100-RHP

RHP MFC100 Four Bolt Round Cast Iron Flanged Bearing Unit and 100mm Insert

RHP MFC100 Four Bolt Round Cast Iron Flanged Bearing Unit and 100mm Insert
$1,025.78 ex VAT
$1,025.78 ex VAT
Sale Sold out

In stock

Price Break
10+ $687.10
20+ $648.50
30+ $640.78
40+ $633.06
50+ $625.34
75+ $617.62
100+ $579.01
200+ $571.29
250+ $563.57
500+ $555.85
1000+ $540.41

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
100mm
Style:
MFC
Pitch Circle Diameter:
260.35mm
Technical
Bore 100mm
L 298.4mm
H 228.6mm
J 260.35mm
G 20mm
A1 88.9mm
A4 46mm
A5 12.7mm
B 117.48mm
s 49.27mm
d1 130.43mm
Dynamic load 157000 N
Static load 122000 N
Rec max speed 1600 rpm
Weight 17.7 kg
Insert <a href="advanced_search_result.php?keywords=3095-100G+insonly">3095-100G Click Here</a>
Casting group 11
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
