SKU: MFC3.1/4-RHP
RHP MFC3-1/4 Four Bolt Round Cast Iron Flanged Bearing Unit and 3-1/4 inch Insert
RHP MFC3-1/4 Four Bolt Round Cast Iron Flanged Bearing Unit and 3-1/4 inch Insert
Regular price
$420.90
ex VAT
Regular price
Sale price
$420.90
ex VAT
In stock
Price Break
10+
$281.94
20+
$266.10
30+
$262.93
40+
$259.76
50+
$256.59
75+
$253.43
100+
$237.59
200+
$234.42
250+
$231.25
500+
$228.08
1000+
$221.75
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 82.55mm = 3.25 (3-1/4) inch
- Style:
- MFC
- Pitch Circle Diameter:
- 190.5mm = 7.5 (7-1/2) inch
Technical
Technical
| Bore | 3-1/4 inch |
|---|---|
| L | 8.748 inch |
| H | 6.375 inch |
| J | 7.5 inch |
| G | 0.625 inch |
| A1 | 2 inch |
| A4 | 0.657 inch |
| A5 | 0.5 inch |
| B | 3.25 inch |
| s | 1.314 inch |
| d1 | 3.878 inch |
| Dynamic load | 71500 N |
| Static load | 54500 N |
| Rec max speed | 2150 rpm |
| Weight | 5.4 kg |
| Insert | <a href="advanced_search_result.php?keywords=1080-3-1/4G+insonly">1080-3-1/4G Click Here</a> |
| Casting group | 9 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
