• RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert
1 1

SKU: MFC3-RHP

RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert

RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert
$420.90 ex VAT
$420.90 ex VAT
Sale Sold out

In stock

Price Break
10+ $281.94
20+ $266.10
30+ $262.93
40+ $259.76
50+ $256.59
75+ $253.43
100+ $237.59
200+ $234.42
250+ $231.25
500+ $228.08
1000+ $221.75

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
76.2mm = 3 inch
Style:
MFC
Pitch Circle Diameter:
190.5mm = 7.5 (7-1/2) inch
Technical
Bore 3 inch
L 8.748 inch
H 6.375 inch
J 7.5 inch
G 0.625 inch
A1 2 inch
A4 0.657 inch
A5 0.5 inch
B 3.25 inch
s 1.314 inch
d1 3.878 inch
Dynamic load 71500 N
Static load 54500 N
Rec max speed 2150 rpm
Weight 5.4 kg
Insert <a href="advanced_search_result.php?keywords=1080-3G+insonly">1080-3G Click Here</a>
Casting group 9
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
