• RHP MFC30 Four Bolt Round Cast Iron Flanged Bearing Unit and 30mm Insert
1 1

SKU: MFC30-RHP

RHP MFC30 Four Bolt Round Cast Iron Flanged Bearing Unit and 30mm Insert

RHP MFC30 Four Bolt Round Cast Iron Flanged Bearing Unit and 30mm Insert
$107.86 ex VAT
$107.86 ex VAT
Sale Sold out

In stock

Price Break
10+ $72.25
20+ $68.19
30+ $67.38
40+ $66.57
50+ $65.76
75+ $64.94
100+ $60.89
200+ $60.07
250+ $59.26
500+ $58.45
1000+ $56.83

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
30mm
Style:
MFC
Pitch Circle Diameter:
104.78mm
Technical
Bore 30mm
L 127mm
H 85.72mm
J 104.78mm
G 10mm
A1 33.32mm
A4 19mm
A5 6.4mm
B 42.88mm
s 17.53mm
d1 46.69mm
Dynamic load 25700 N
Static load 15300 N
Rec max speed 4500 rpm
Weight 1.5 kg
Insert <a href="advanced_search_result.php?keywords=1035-30G+insonly">1035-30G Click Here</a>
Casting group 2
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
