• RHP MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert
1 1

SKU: MFC4-RHP

RHP MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert

RHP MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert
$1,088.14 ex VAT
$1,088.14 ex VAT
Sale Sold out

In stock

Price Break
10+ $728.87
20+ $687.92
30+ $679.73
40+ $671.54
50+ $663.35
75+ $655.16
100+ $614.21
200+ $606.02
250+ $597.84
500+ $589.65
1000+ $573.27

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
101.6mm = 4 inch
Style:
MFC
Pitch Circle Diameter:
260.35mm = 10.25 (10-1/4) inch
Technical
Bore 4 inch
L 11.748 inch
H 9 inch
J 10.25 inch
G 0.75 inch
A1 3.5 inch
A4 1.811 inch
A5 0.5 inch
B 4.625 inch
s 1.94 inch
d1 5.135 inch
Dynamic load 157000 N
Static load 122000 N
Rec max speed 1600 rpm
Weight 17.7 kg
Insert <a href="advanced_search_result.php?keywords=3095-4G+insonly">3095-4G Click Here</a>
Casting group 11
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
