• RHP MFC85 Four Bolt Round Cast Iron Flanged Bearing Unit and 85mm Insert
1 1

SKU: MFC85-RHP

RHP MFC85 Four Bolt Round Cast Iron Flanged Bearing Unit and 85mm Insert

RHP MFC85 Four Bolt Round Cast Iron Flanged Bearing Unit and 85mm Insert
$666.54 ex VAT
$666.54 ex VAT
Sale Sold out

In stock

Price Break
10+ $446.47
20+ $421.39
30+ $416.37
40+ $411.35
50+ $406.34
75+ $401.32
100+ $376.24
200+ $371.22
250+ $366.20
500+ $361.19
1000+ $351.15

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
85mm
Style:
MFC
Pitch Circle Diameter:
219.08mm
Technical
Bore 85mm
L 260.4mm
H 187.32mm
J 219.08mm
G 20mm
A1 67.46mm
A4 29.4mm
A5 12.7mm
B 96.04mm
s 39.73mm
d1 111.66mm
Dynamic load 96000 N
Static load 71500 N
Rec max speed 1900 rpm
Weight 9.8 kg
Insert <a href="advanced_search_result.php?keywords=1090-85G+insonly">1090-85G Click Here</a>
Casting group 10
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
