SKU: MSF1.15/16-RHP
RHP MSF1-15/16 Imperial Four Bolt Square Cast Iron Flange Housing and 1-15/16 inch Bore Grub Screw Insert
RHP MSF1-15/16 Imperial Four Bolt Square Cast Iron Flange Housing and 1-15/16 inch Bore Grub Screw Insert
Regular price
$174.44
ex VAT
Regular price
Sale price
$174.44
ex VAT
In stock
Price Break
10+
$116.85
20+
$110.28
30+
$108.97
40+
$107.66
50+
$106.34
75+
$105.03
100+
$98.47
200+
$97.15
250+
$95.84
500+
$94.53
1000+
$91.90
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 49.21mm = 1.937 (1-15/16) inch
- Style:
- MSF
- Bolt Hole Centres:
- 129.997mm = 5.118 inch
Technical
Technical
| Bore | 1-15/16 inch |
|---|---|
| L | 6.374 inch |
| H | 5 inch |
| J | 5.118 inch |
| G | 0.625 inch |
| A | 1.72 inch |
| A1 | 2.532 inch |
| A4 | 0.689 inch |
| B | 2.187 inch |
| s | 0.877 inch |
| d1 | 2.709 inch |
| Dynamic load cr | 43500 N |
| Static load Cor | 29200 N |
| Rec max speed | 3100 rpm |
| Weight | 4 kg |
| Insert | <a href="advanced_search_result.php?keywords=1055-1-15/16G+insonly">1055-1-15/16G Click Here</a> |
| Casting group | 6 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
