• RHP MSF1 Imperial Four Bolt Square Cast Iron Flange Housing and 1 inch Bore Grub Screw Insert
1 1

SKU: MSF1-RHP

RHP MSF1 Imperial Four Bolt Square Cast Iron Flange Housing and 1 inch Bore Grub Screw Insert

RHP MSF1 Imperial Four Bolt Square Cast Iron Flange Housing and 1 inch Bore Grub Screw Insert
$74.75 ex VAT
$74.75 ex VAT
Sale Sold out

In stock

Price Break
10+ $50.07
20+ $47.26
30+ $46.70
40+ $46.14
50+ $45.57
75+ $45.01
100+ $42.20
200+ $41.64
250+ $41.07
500+ $40.51
1000+ $39.38

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
25.4mm = 1 inch
Style:
MSF
Bolt Hole Centres:
82.5mm = 3.248 inch
Technical
Bore 1 inch
L 4.252 inch
H 3.252 inch
J 3.248 inch
G 0.4375 inch
A 1.173 inch
A1 1.662 inch
A4 0.5 inch
B 1.5 inch
s 0.627 inch
d1 1.575 inch
Dynamic load cr 19500 N
Static load Cor 11300 N
Rec max speed 5300 rpm
Weight 1.3 kg
Insert <a href="advanced_search_result.php?keywords=1030-1G+insonly">1030-1G Click Here</a>
Casting group 1
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
