• RHP MSF1025-20K Metric Four Bolt Square Cast Iron Flange Housing and 20mm Bore Taper Sleeve Insert
1 1

SKU: MSF1025-20K-RHP

RHP MSF1025-20K Metric Four Bolt Square Cast Iron Flange Housing and 20mm Bore Taper Sleeve Insert

RHP MSF1025-20K Metric Four Bolt Square Cast Iron Flange Housing and 20mm Bore Taper Sleeve Insert
$64.35 ex VAT
$64.35 ex VAT
Sale Sold out

In stock

Price Break
10+ $43.10
20+ $40.68
30+ $40.19
40+ $39.71
50+ $39.23
75+ $38.74
100+ $36.32
200+ $35.84
250+ $35.35
500+ $34.87
1000+ $33.90

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
20mm
Style:
MSF
Bolt Hole Centres:
70mm
Technical
Bore 20mm
L 95.3mm
H 68mm
J 70mm
G 10mm
A 28.6mm
A1 -mm
A4 11.1mm
B -mm
s -mm
d1 -mm
Dynamic load cr 14000 N
Static load Cor 7880 N
Rec max speed 6250 rpm
Weight 1 kg
Insert <a href="advanced_search_result.php?keywords=1025K+insonly">1025K Click Here</a>
Casting group SF3
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
