• RHP MSF1030-1K Imperial Four Bolt Square Cast Iron Flange Housing and 1 inch Bore Taper Sleeve Insert
1 1

SKU: MSF1030-1K-RHP

RHP MSF1030-1K Imperial Four Bolt Square Cast Iron Flange Housing and 1 inch Bore Taper Sleeve Insert

RHP MSF1030-1K Imperial Four Bolt Square Cast Iron Flange Housing and 1 inch Bore Taper Sleeve Insert
$96.38 ex VAT
$96.38 ex VAT
Sale Sold out

In stock

Price Break
10+ $64.56
20+ $60.94
30+ $60.21
40+ $59.49
50+ $58.76
75+ $58.04
100+ $54.41
200+ $53.68
250+ $52.96
500+ $52.23
1000+ $50.78

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
25.4mm = 1 inch
Style:
MSF
Bolt Hole Centres:
82.5mm = 3.248 inch
Technical
Bore 1 inch
L 4.252 inch
H 3.252 inch
J 3.248 inch
G 0.4375 inch
A 1.173 inch
A1 - inch
A4 0.5 inch
B - inch
s - inch
d1 - inch
Dynamic load cr 19500 N
Static load Cor 11300 N
Rec max speed 5300 rpm
Weight 1.3 kg
Insert <a href="advanced_search_result.php?keywords=1030K+insonly">1030K Click Here</a>
Casting group 1
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
