• RHP MSF1040K Metric Four Bolt Square Cast Iron Flange Housing and 35mm Bore Taper Sleeve Insert
1 1

SKU: MSF1040K-RHP

RHP MSF1040K Metric Four Bolt Square Cast Iron Flange Housing and 35mm Bore Taper Sleeve Insert

RHP MSF1040K Metric Four Bolt Square Cast Iron Flange Housing and 35mm Bore Taper Sleeve Insert
$117.07 ex VAT
$117.07 ex VAT
Sale Sold out

In stock

Price Break
10+ $78.42
20+ $74.01
30+ $73.13
40+ $72.25
50+ $71.37
75+ $70.49
100+ $66.08
200+ $65.20
250+ $64.32
500+ $63.44
1000+ $61.68

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
35mm
Style:
MSF
Bolt Hole Centres:
101.5mm
Technical
Bore 35mm
L 130.2mm
H 101.6mm
J 101.5mm
G 12mm
A 34.9mm
A1 -mm
A4 12.7mm
B -mm
s -mm
d1 -mm
Dynamic load cr 32500 N
Static load Cor 19900 N
Rec max speed 4000 rpm
Weight 2.2 kg
Insert <a href="advanced_search_result.php?keywords=1040K+insonly">1040K Click Here</a>
Casting group 3
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
Reviews
View full details
