• RHP MSF1045-1-1/2K Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/2 inch Bore Taper Sleeve Insert
1 1

SKU: MSF1045-1.1/2K-RHP

RHP MSF1045-1-1/2K Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/2 inch Bore Taper Sleeve Insert

RHP MSF1045-1-1/2K Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/2 inch Bore Taper Sleeve Insert
$158.53 ex VAT
$158.53 ex VAT
Sale Sold out

In stock

Price Break
10+ $106.18
20+ $100.22
30+ $99.02
40+ $97.83
50+ $96.64
75+ $95.44
100+ $89.48
200+ $88.29
250+ $87.09
500+ $85.90
1000+ $83.51

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
38.1mm = 1.5 (1-1/2) inch
Style:
MSF
Bolt Hole Centres:
105.004mm = 4.134 inch
Technical
Bore 1-1/2 inch
L 5.374 inch
H 4.374 inch
J 4.134 inch
G 0.625 inch
A 1.39 inch
A1 - inch
A4 0.563 inch
B - inch
s - inch
d1 - inch
Dynamic load cr 32500 N
Static load Cor 20500 N
Rec max speed 3700 rpm
Weight 2.6 kg
Insert <a href="advanced_search_result.php?keywords=1045K+insonly">1045K Click Here</a>
Casting group 4
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
