• RHP MSF1055-2K Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Taper Sleeve Insert
1 1

SKU: MSF1055-2K-RHP

RHP MSF1055-2K Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Taper Sleeve Insert

RHP MSF1055-2K Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Taper Sleeve Insert
$256.84 ex VAT
$256.84 ex VAT
Sale Sold out

In stock

Price Break
10+ $172.04
20+ $162.38
30+ $160.44
40+ $158.51
50+ $156.58
75+ $154.64
100+ $144.98
200+ $143.05
250+ $141.11
500+ $139.18
1000+ $135.31

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
50.8mm = 2 inch
Style:
MSF
Bolt Hole Centres:
129.997mm = 5.118 inch
Technical
Bore 2 inch
L 6.374 inch
H 5000 inch
J 5.118 inch
G 0.625 inch
A 1.72 inch
A1 - inch
A4 0.689 inch
B - inch
s - inch
d1 - inch
Dynamic load cr 43500 N
Static load Cor 29200 N
Rec max speed 3100 rpm
Weight 4 kg
Insert <a href="advanced_search_result.php?keywords=1055K+insonly">1055K Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
