• RHP MSF1055-50K Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Taper Sleeve Insert
1 1

SKU: MSF1055-50K-RHP

RHP MSF1055-50K Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Taper Sleeve Insert

RHP MSF1055-50K Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Taper Sleeve Insert
$242.14 ex VAT
$242.14 ex VAT
Sale Sold out

In stock

Price Break
10+ $162.20
20+ $153.08
30+ $151.26
40+ $149.44
50+ $147.62
75+ $145.80
100+ $136.68
200+ $134.86
250+ $133.04
500+ $131.22
1000+ $127.57

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
50mm
Style:
MSF
Bolt Hole Centres:
130mm
Technical
Bore 50mm
L 161.9mm
H 127mm
J 130mm
G 16mm
A 43.7mm
A1 -mm
A4 17.5mm
B -mm
s -mm
d1 -mm
Dynamic load cr 43500 N
Static load Cor 29200 N
Rec max speed 3100 rpm
Weight 4 kg
Insert <a href="advanced_search_result.php?keywords=1055K+insonly">1055K Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
