• RHP MSF1055K Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Taper Sleeve Insert
1 1

SKU: MSF1055K-RHP

RHP MSF1055K Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Taper Sleeve Insert

RHP MSF1055K Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Taper Sleeve Insert
$205.23 ex VAT
$205.23 ex VAT
Sale Sold out

In stock

Price Break
10+ $137.47
20+ $129.75
30+ $128.20
40+ $126.66
50+ $125.11
75+ $123.57
100+ $115.85
200+ $114.30
250+ $112.76
500+ $111.21
1000+ $108.12

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
50mm
Style:
MSF
Bolt Hole Centres:
130mm
Technical
Bore 50mm
L 161.9mm
H 127mm
J 130mm
G 16mm
A 43.7mm
A1 -mm
A4 17.5mm
B -mm
s -mm
d1 -mm
Dynamic load cr 43500 N
Static load Cor 29200 N
Rec max speed 3100 rpm
Weight 4 kg
Insert <a href="advanced_search_result.php?keywords=1055K+insonly">1055K Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
