• RHP MSF2-11/16 Imperial Four Bolt Square Cast Iron Flange Housing and 2-11/16 inch Bore Grub Screw Insert
1 1

SKU: MSF2.11/16-RHP

RHP MSF2-11/16 Imperial Four Bolt Square Cast Iron Flange Housing and 2-11/16 inch Bore Grub Screw Insert

RHP MSF2-11/16 Imperial Four Bolt Square Cast Iron Flange Housing and 2-11/16 inch Bore Grub Screw Insert
$374.17 ex VAT
$374.17 ex VAT
Sale Sold out

In stock

Price Break
10+ $250.64
20+ $236.55
30+ $233.74
40+ $230.92
50+ $228.11
75+ $225.29
100+ $211.21
200+ $208.39
250+ $205.58
500+ $202.76
1000+ $197.13

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
68.26mm = 2.687 (2-11/16) inch
Style:
MSF
Bolt Hole Centres:
152.4mm = 6 inch
Technical
Bore 2-11/16 inch
L 7.736 inch
H 6.24 inch
J 6 inch
G 0.75 inch
A 2.02 inch
A1 3.185 inch
A4 0.906 inch
B 3.062 inch
s 1.314 inch
d1 3.622 inch
Dynamic load cr 66000 N
Static load Cor 49500 N
Rec max speed 2300 rpm
Weight 8.6 kg
Insert <a href="advanced_search_result.php?keywords=1075-2-11/16G+insonly">1075-2-11/16G Click Here</a>
Casting group 9
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
