• RHP MSF2 Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Grub Screw Insert
1 1

SKU: MSF2-RHP

RHP MSF2 Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Grub Screw Insert

RHP MSF2 Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Grub Screw Insert
$174.44 ex VAT
$174.44 ex VAT
Sale Sold out

In stock

Price Break
10+ $116.85
20+ $110.28
30+ $108.97
40+ $107.66
50+ $106.34
75+ $105.03
100+ $98.47
200+ $97.15
250+ $95.84
500+ $94.53
1000+ $91.90

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
50.8mm = 2 inch
Style:
MSF
Bolt Hole Centres:
129.997mm = 5.118 inch
Technical
Bore 2 inch
L 6.374 inch
H 5 inch
J 5.118 inch
G 0.625 inch
A 1.72 inch
A1 2.532 inch
A4 0.689 inch
B 2.187 inch
s 0.877 inch
d1 2.709 inch
Dynamic load cr 43500 N
Static load Cor 29200 N
Rec max speed 3100 rpm
Weight 4 kg
Insert <a href="advanced_search_result.php?keywords=1055-2G+insonly">1055-2G Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
