• RHP MSF3-1/4 Imperial Four Bolt Square Cast Iron Flange Housing and 3-1/4 inch Bore Grub Screw Insert
1 1

SKU: MSF3.1/4-RHP

RHP MSF3-1/4 Imperial Four Bolt Square Cast Iron Flange Housing and 3-1/4 inch Bore Grub Screw Insert

RHP MSF3-1/4 Imperial Four Bolt Square Cast Iron Flange Housing and 3-1/4 inch Bore Grub Screw Insert
$515.56 ex VAT
$515.56 ex VAT
Sale Sold out

In stock

Price Break
10+ $345.34
20+ $325.94
30+ $322.06
40+ $318.18
50+ $314.30
75+ $310.42
100+ $291.01
200+ $287.13
250+ $283.25
500+ $279.37
1000+ $271.61

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
82.55mm = 3.25 (3-1/4) inch
Style:
MSF
Bolt Hole Centres:
171.45mm = 6.75 inch
Technical
Bore 3-1/4 inch
L 8.406 inch
H 7.244 inch
J 6.75 inch
G 0.75 inch
A 2.138 inch
A1 3.529 inch
A4 1.024 inch
B 3.375 inch
s 1.346 inch
d1 4.174 inch
Dynamic load cr 83000 N
Static load Cor 64000 N
Rec max speed 2000 rpm
Weight 11.1 kg
Insert <a href="advanced_search_result.php?keywords=1085-3-1/4G+insonly">1085-3-1/4G Click Here</a>
Casting group 11
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
