SKU: MSF3.7/16-RHP

RHP MSF3-7/16 Imperial Four Bolt Square Cast Iron Flange Housing and 3-7/16 inch Bore Grub Screw Insert

RHP MSF3-7/16 Imperial Four Bolt Square Cast Iron Flange Housing and 3-7/16 inch Bore Grub Screw Insert
Regular price $675.68 ex VAT
Regular price Sale price $675.68 ex VAT
Sale Sold out

In stock

Price Break
10+ $452.59
20+ $427.17
30+ $422.08
40+ $417.00
50+ $411.91
75+ $406.82
100+ $381.40
200+ $376.31
250+ $371.23
500+ $366.14
1000+ $355.97
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 3-7/16 inch
L 8.406 inch
H 7.736 inch
J 6.75 inch
G 0.75 inch
A 2.429 inch
A1 3.967 inch
A4 1.024 inch
B 3.781 inch
s 1.564 inch
d1 4.396 inch
Dynamic load cr 96000 N
Static load Cor 71500 N
Rec max speed 1900 rpm
Weight 13.2 kg
Insert <a href="advanced_search_result.php?keywords=1090-3-7/16G+insonly">1090-3-7/16G Click Here</a>
Casting group 12
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
