• RHP MSF3 Imperial Four Bolt Square Cast Iron Flange Housing and 3 inch Bore Grub Screw Insert
1 1

SKU: MSF3-RHP

RHP MSF3 Imperial Four Bolt Square Cast Iron Flange Housing and 3 inch Bore Grub Screw Insert

RHP MSF3 Imperial Four Bolt Square Cast Iron Flange Housing and 3 inch Bore Grub Screw Insert
$431.44 ex VAT
$431.44 ex VAT
Sale Sold out

In stock

Price Break
10+ $289.00
20+ $272.76
30+ $269.51
40+ $266.27
50+ $263.02
75+ $259.77
100+ $243.54
200+ $240.29
250+ $237.04
500+ $233.79
1000+ $227.30

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
76.2mm = 3 inch
Style:
MSF
Bolt Hole Centres:
152.4mm = 6 inch
Technical
Bore 3 inch
L 7.736 inch
H 6.831 inch
J 6 inch
G 0.75 inch
A 2.165 inch
A1 3.499 inch
A4 0.906 inch
B 3.25 inch
s 1.314 inch
d1 3.878 inch
Dynamic load cr 71500 N
Static load Cor 54500 N
Rec max speed 2150 rpm
Weight 9.3 kg
Insert <a href="advanced_search_result.php?keywords=1080-3G+insonly">1080-3G Click Here</a>
Casting group 10
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
