SKU: MSF30-RHP

RHP MSF30 Metric Four Bolt Square Cast Iron Flange Housing and 30mm Bore Grub Screw Insert

Name: RHP MSF30 Metric Four Bolt Square Cast Iron Flange Housing and 30mm Bore Grub Screw Insert
Brand: RHP
SKU: MSF30-RHP
Price: 81.73 USD
Availability: InStock

$81.73 ex VAT

Sale Sold out

In stock

Price Break

10+ $54.75

20+ $51.67

30+ $51.06

40+ $50.44

50+ $49.83

75+ $49.21

100+ $46.14

200+ $45.52

250+ $44.91

500+ $44.29

1000+ $43.06

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: RHP - High Quality
Inside Diameter:: 30mm
Style:: MSF
Bolt Hole Centres:: 92mm

Technical

Bore	30mm
L	117.5mm
H	95.3mm
J	92mm
G	12mm
A	31.4mm
A1	46.41mm
A4	12.7mm
B	42.88mm
s	17.53mm
d1	46.69mm
Dynamic load cr	25700 N
Static load Cor	15300 N
Rec max speed	4500 rpm
Weight	1.7 kg
Insert	<a href="advanced_search_result.php?keywords=1035-30G+insonly">1035-30G Click Here</a>
Casting group	2
Grease nipple thread	1/4 UNF, 1/4 inch x 28 TPI
