• RHP MSF4 Imperial Four Bolt Square Cast Iron Flange Housing and 4 inch Bore Grub Screw Insert
1 1

SKU: MSF4-RHP

RHP MSF4 Imperial Four Bolt Square Cast Iron Flange Housing and 4 inch Bore Grub Screw Insert

RHP MSF4 Imperial Four Bolt Square Cast Iron Flange Housing and 4 inch Bore Grub Screw Insert
$1,013.36 ex VAT
$1,013.36 ex VAT
Sale Sold out

In stock

Price Break
10+ $678.78
20+ $640.64
30+ $633.02
40+ $625.39
50+ $617.76
75+ $610.14
100+ $572.00
200+ $564.38
250+ $556.75
500+ $549.12
1000+ $533.87

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
101.6mm = 4 inch
Style:
MSF
Bolt Hole Centres:
211.125mm = 8.312 inch
Technical
Bore 4 inch
L 10.531 inch
H 9.272 inch
J 8.312 inch
G 1 inch
A 3.287 inch
A1 4.998 inch
A4 1.26 inch
B 4.625 inch
s 1.94 inch
d1 5.135 inch
Dynamic load cr 157000 N
Static load Cor 122020 N
Rec max speed 1600 rpm
Weight 24.7 kg
Insert <a href="advanced_search_result.php?keywords=3095-4G+insonly">3095-4G Click Here</a>
Casting group 13
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
