• RHP MSF40 Metric Four Bolt Square Cast Iron Flange Housing and 40mm Bore Grub Screw Insert
1 1

SKU: MSF40-RHP

RHP MSF40 Metric Four Bolt Square Cast Iron Flange Housing and 40mm Bore Grub Screw Insert

RHP MSF40 Metric Four Bolt Square Cast Iron Flange Housing and 40mm Bore Grub Screw Insert
$107.50 ex VAT
$107.50 ex VAT
Sale Sold out

In stock

Price Break
10+ $72.01
20+ $67.97
30+ $67.16
40+ $66.35
50+ $65.54
75+ $64.73
100+ $60.69
200+ $59.88
250+ $59.07
500+ $58.26
1000+ $56.64

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
40mm
Style:
MSF
Bolt Hole Centres:
105mm
Technical
Bore 40mm
L 136.5mm
H 111.1mm
J 105mm
G 16mm
A 35.3mm
A1 54.18mm
A4 14.3mm
B 49.23mm
s 19.1mm
d1 57.3mm
Dynamic load cr 32500 N
Static load Cor 20500 N
Rec max speed 3700 rpm
Weight 2.6 kg
Insert <a href="advanced_search_result.php?keywords=1045-40G+insonly">1045-40G Click Here</a>
Casting group 4
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
