• RHP MSF50 Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Grub Screw Insert
1 1

SKU: MSF50-RHP

RHP MSF50 Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Grub Screw Insert

RHP MSF50 Metric Four Bolt Square Cast Iron Flange Housing and 50mm Bore Grub Screw Insert
$164.43 ex VAT
$164.43 ex VAT
Sale Sold out

In stock

Price Break
10+ $110.13
20+ $103.95
30+ $102.71
40+ $101.47
50+ $100.23
75+ $99.00
100+ $92.81
200+ $91.57
250+ $90.34
500+ $89.10
1000+ $86.62

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
50mm
Style:
MSF
Bolt Hole Centres:
130mm
Technical
Bore 50mm
L 161.9mm
H 127mm
J 130mm
G 16mm
A 43.7mm
A1 64.31mm
A4 17.5mm
B 55.55mm
s 22.28mm
d1 68.81mm
Dynamic load cr 43500 N
Static load Cor 29200 N
Rec max speed 3100 rpm
Weight 4 kg
Insert <a href="advanced_search_result.php?keywords=1055-50G+insonly">1055-50G Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
