• RHP MSF70 Metric Four Bolt Square Cast Iron Flange Housing and 70mm Bore Grub Screw Insert
1 1

SKU: MSF70-RHP

RHP MSF70 Metric Four Bolt Square Cast Iron Flange Housing and 70mm Bore Grub Screw Insert

RHP MSF70 Metric Four Bolt Square Cast Iron Flange Housing and 70mm Bore Grub Screw Insert
$352.73 ex VAT
$352.73 ex VAT
Sale Sold out

In stock

Price Break
10+ $236.27
20+ $223.00
30+ $220.34
40+ $217.69
50+ $215.03
75+ $212.38
100+ $199.10
200+ $196.45
250+ $193.79
500+ $191.14
1000+ $185.83

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
70mm
Style:
MSF
Bolt Hole Centres:
152.4mm
Technical
Bore 70mm
L 196.5mm
H 158.5mm
J 152.4mm
G 20mm
A 51.3mm
A1 80.9mm
A4 23mm
B 77.77mm
s 33.37mm
d1 92mm
Dynamic load cr 66000 N
Static load Cor 49500 N
Rec max speed 2300 rpm
Weight 8.6 kg
Insert <a href="advanced_search_result.php?keywords=1075-70G+insonly">1075-70G Click Here</a>
Casting group 9
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
