• RHP MSF75 Metric Four Bolt Square Cast Iron Flange Housing and 75mm Bore Grub Screw Insert
1 1

SKU: MSF75-RHP

RHP MSF75 Metric Four Bolt Square Cast Iron Flange Housing and 75mm Bore Grub Screw Insert

RHP MSF75 Metric Four Bolt Square Cast Iron Flange Housing and 75mm Bore Grub Screw Insert
$406.73 ex VAT
$406.73 ex VAT
Sale Sold out

In stock

Price Break
10+ $272.44
20+ $257.13
30+ $254.07
40+ $251.01
50+ $247.95
75+ $244.89
100+ $229.58
200+ $226.52
250+ $223.46
500+ $220.40
1000+ $214.28

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
75mm
Style:
MSF
Bolt Hole Centres:
152.4mm
Technical
Bore 75mm
L 196.5mm
H 173.5mm
J 152.4mm
G 20mm
A 55mm
A1 88.87mm
A4 23mm
B 82.55mm
s 33.37mm
d1 98.5mm
Dynamic load cr 71500 N
Static load Cor 54500 N
Rec max speed 2150 rpm
Weight 9.3 kg
Insert <a href="advanced_search_result.php?keywords=1080-75G+insonly">1080-75G Click Here</a>
Casting group 10
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
