• RHP MSF80 Metric Four Bolt Square Cast Iron Flange Housing and 80mm Bore Grub Screw Insert
1 1

SKU: MSF80-RHP

RHP MSF80 Metric Four Bolt Square Cast Iron Flange Housing and 80mm Bore Grub Screw Insert

RHP MSF80 Metric Four Bolt Square Cast Iron Flange Housing and 80mm Bore Grub Screw Insert
$486.04 ex VAT
$486.04 ex VAT
Sale Sold out

In stock

Price Break
10+ $325.57
20+ $307.28
30+ $303.62
40+ $299.96
50+ $296.30
75+ $292.64
100+ $274.35
200+ $270.69
250+ $267.04
500+ $263.38
1000+ $256.06

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
80mm
Style:
MSF
Bolt Hole Centres:
171.45mm
Technical
Bore 80mm
L 213.5mm
H 184mm
J 171.45mm
G 20mm
A 54.3mm
A1 89.64mm
A4 26mm
B 85.72mm
s 34.18mm
d1 106.02mm
Dynamic load cr 83000 N
Static load Cor 64000 N
Rec max speed 2000 rpm
Weight 11.1 kg
Insert <a href="advanced_search_result.php?keywords=1085-80G+insonly">1085-80G Click Here</a>
Casting group 11
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
