• NA22082RS Budget Support Roller no Axial Guidance with Inner Sleeve 40x80x22.7mm
1 1

SKU: NA2208.2RS-EU

NA22082RS Budget Support Roller no Axial Guidance with Inner Sleeve 40x80x22.7mm

NA22082RS Budget Support Roller no Axial Guidance with Inner Sleeve 40x80x22.7mm
$66.82 ex VAT
$66.82 ex VAT
Sale Sold out

Equivalent to: NA2208LL

In stock

Price Break
10+ $44.76
19+ $42.24
29+ $41.74
39+ $41.24
49+ $40.74
74+ $40.23
99+ $37.72
199+ $37.22
249+ $36.71
499+ $36.21
999+ $35.20

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

Budget Support Rollers without Axial Guidance: Designed for applications where the associated components can be designed to to provide the axial guidance. The support rollers are supplied with inner rings and are intended for arrangements where the pin or shaft can be hardened and ground.
Benefits: Supplied with the inner ring, separable - easily mounted

Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
40mm
Outside Diameter:
80mm
Width:
22.7mm
Seals / Shields:
Rubber Seals
Technical
D 80mm
C 22.7mm
d 40mm
B 23mm
D1 57mm
F 48mm
r min 1.1mm
r1r2 min 0.6mm
Speed rating 850 rpm
Dynamic load 27000 N
Basic static load 39000 N
Fatigue load limit Pu 4900 N
Max radial dynamic force 37500 N
Max radial static force 53000 N
Weight 630 g
