• NA22092RS Budget Support Roller no Axial Guidance with Inner Sleeve 45x85x22.7mm
1 1

SKU: NA2209.2RS-EU

NA22092RS Budget Support Roller no Axial Guidance with Inner Sleeve 45x85x22.7mm

NA22092RS Budget Support Roller no Axial Guidance with Inner Sleeve 45x85x22.7mm
$165.28 ex VAT
$165.28 ex VAT
Sale Sold out

Equivalent to: NA2209LL

In stock

Price Break
10+ $110.70
19+ $104.48
29+ $103.24
39+ $102.00
49+ $100.75
74+ $99.51
99+ $93.29
199+ $92.05
249+ $90.80
499+ $89.56
999+ $87.07

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

Budget Support Rollers without Axial Guidance: Designed for applications where the associated components can be designed to to provide the axial guidance. The support rollers are supplied with inner rings and are intended for arrangements where the pin or shaft can be hardened and ground.
Benefits: Supplied with the inner ring, separable - easily mounted

Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
45mm
Outside Diameter:
85mm
Width:
22.7mm
Seals / Shields:
Rubber Seals
Technical
D 85mm
C 22.7mm
d 45mm
B 23mm
D1 62mm
F 52mm
r min 1.1mm
r1r2 min 0.6mm
Speed rating 800 rpm
Dynamic load 27500 N
Basic static load 41500 N
Fatigue load limit Pu 5200 N
Max radial dynamic force 39000 N
Max radial static force 56000 N
Weight 660 g
