SKU: NAO9x22x12-EU

NAO9x22x12 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve

Name: NAO9x22x12 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
Brand: Gen
SKU: NAO9x22x12-EU
Price: 10.66 USD
Availability: InStock

$10.66 ex VAT

Sale Sold out

In stock

Price Break

10+ $7.14

19+ $6.74

29+ $6.66

39+ $6.58

49+ $6.50

74+ $6.42

99+ $6.02

199+ $5.94

249+ $5.86

499+ $5.78

999+ $5.62

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting.
Benefits: Separable, ease of mounting.

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 9mm
Outside Diameter:: 22mm
Width:: 12mm

Technical

d	9mm
D	22mm
B	12mm
Dynamic load C	9520 N
Static load Co	10000 N
Fatigue load limit Pu	1180 N
Speed in grease	17000 rpm
Speed in oil	26000 rpm
E	18mm
F	12mm
r1r2 min	0.3mm
S (axial disp)	0.5mm
da	17.6mm
db	11.7mm
Da	18.3mm
Db	12.3mm
ra max	0.3mm
Weight	24 g
