• SKF NU322ECMC3VL0241 Insocoat Cylindrical Roller Bearing 110x240x50mm
1 1

SKU: NU322ECM/C3VL0241-SKF

SKF NU322ECMC3VL0241 Insocoat Cylindrical Roller Bearing 110x240x50mm

SKF NU322ECMC3VL0241 Insocoat Cylindrical Roller Bearing 110x240x50mm
$2,505.87 ex VAT
$2,505.87 ex VAT
Sale Sold out

In stock

Price Break
10+ $1,678.51
19+ $1,584.21
29+ $1,565.35
39+ $1,546.49
49+ $1,527.63
74+ $1,508.77
99+ $1,414.47
199+ $1,395.61
249+ $1,376.75
499+ $1,357.89
999+ $1,320.17

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Insocoat Bearings: Special application bearings that are electrically insulated and capable of withstanding voltages up to 1000v, a layer of aluminium oxide (100µm thickness)
Benefits: Electrically insulated
Brand / Quality:
SKF - High Quality
Inside Diameter:
110mm
Outside Diameter:
240mm
Width:
50mm
Seals / Shields:
None
Clearance:
C3
Technical
d 110mm
D 240mm
B 50mm
Dynamic load C 530 kN
Static load Co 540 kN
Fatigue load limit Pu 61 kN
Reference speed 3000 rpm
Limiting speed 3400 rpm
Weight 12 kg
D1 201mm
F 143mm
r1r2 min 3mm
r1r4 min 3mm
s 3mm
da min 124mm
da max 139mm
db min 146mm
Da min 207mm
Da max 226mm
ra max 2.5mm
rb max 2.5mm
kr 0.15
