• SKF NU324ECMC3VL0241 Insocoat Cylindrical Roller Bearing 120x260x55mm
1 1

SKU: NU324ECM/C3VL0241-SKF

SKF NU324ECMC3VL0241 Insocoat Cylindrical Roller Bearing 120x260x55mm

SKF NU324ECMC3VL0241 Insocoat Cylindrical Roller Bearing 120x260x55mm
$2,848.41 ex VAT
$2,848.41 ex VAT
Sale Sold out

In stock

Price Break
10+ $1,907.95
19+ $1,800.76
29+ $1,779.32
39+ $1,757.88
49+ $1,736.45
74+ $1,715.01
99+ $1,607.82
199+ $1,586.38
249+ $1,564.95
499+ $1,543.51
999+ $1,500.63

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Insocoat Bearings: Special application bearings that are electrically insulated and capable of withstanding voltages up to 1000v, a layer of aluminium oxide (100µm thickness)
Benefits: Electrically insulated
Brand / Quality:
SKF - High Quality
Inside Diameter:
120mm
Outside Diameter:
260mm
Width:
55mm
Seals / Shields:
None
Clearance:
C3
Technical
d 120mm
D 260mm
B 55mm
Dynamic load C 610 kN
Static load Co 620 kN
Fatigue load limit Pu 69.5 kN
Reference speed 2800 rpm
Limiting speed 3200 rpm
Weight 15.2 kg
D1 219mm
F 154mm
r1r2 min 3mm
r1r4 min 3mm
s 3.7mm
da min 134mm
da max 150mm
db min 157mm
Da min 225mm
Da max 246mm
ra max 2.5mm
rb max 2.5mm
kr 0.15
