SKU: NX7ZTN-EU

NX7ZTN Budget Full Comp Needle / Ball Thrust Bearing / Closure Ring 7x14x18mm

Name: NX7ZTN Budget Full Comp Needle / Ball Thrust Bearing / Closure Ring 7x14x18mm
Brand: Gen
SKU: NX7ZTN-EU
Price: 21.58 USD
Availability: InStock

$21.58 ex VAT

Sale Sold out

In stock

Price Break

10+ $14.45

19+ $13.64

29+ $13.48

39+ $13.31

49+ $13.15

74+ $12.99

99+ $12.18

199+ $12.02

249+ $11.85

499+ $11.69

999+ $11.37

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 7mm
Outside Diameter:: 14mm
Width:: 18mm
Seals / Shields:: Metal Shields

Technical

Fw	7mm
D	14mm
C	18mm
Dynamic load	2810 N
Static load	2750 N
Axial dynamic load	3450 N
Axial static load	5000 N
Radial fatigue load limit Pu	290 N
Axial fatigue load limit Pu	186 N
Min load factor A	0.13
Speed in grease	7500 rpm
C1	4.7mm
d	7mm
r1r2 min	0.3mm
da	9.5mm
Da max	12mm
Ca	10mm
ra max	0.3mm
Retaining ring	SW14
Weight	14 g
