• P84-H-200 - 1/2 inch Pitch 84 Tooth Pilot Bored Cast Iron Timing Pulley for 2 inch Wide Belts
1 1

SKU: P84-H-200

P84-H-200 - 1/2 inch Pitch 84 Tooth Pilot Bored Cast Iron Timing Pulley for 2 inch Wide Belts

P84-H-200 - 1/2 inch Pitch 84 Tooth Pilot Bored Cast Iron Timing Pulley for 2 inch Wide Belts
$187.84 ex VAT
$187.84 ex VAT
Sale Sold out

Equivalent to: P84H200

In stock

Price Break
3+ $125.82
5+ $118.75
9+ $117.34
19+ $115.93
49+ $114.51
74+ $113.10
99+ $106.03
199+ $104.62
249+ $103.20
499+ $101.79
999+ $98.96

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Drive-Flex - High Quality
Teeth:
84
Material:
Cast Iron
Belt Width Approx:
50.8mm = 2 inch
Pitch:
12.7mm = 0.5 (1/2) inch
Item Type:
Flangeless Pilot Bored Pulley
Technical
No. teeth 84
Dp 339.57mm
De 338.2mm
Dm 120mm
F 58.7mm
L 75mm
d 28
Material Cast Iron
Bore Pilot Bored
Belt Width 50.8mm = 2 inch
Pitch 12.7mm = 0.5 (1/2) inch
