• PBMF658035M1G1 Premier Budget Metric Flanged Solid Bronze Bush 65x80x35mm (Allow 6-8 Weeks)
1 1

SKU: PBMF658035M1G1-EU

PBMF658035M1G1 Premier Budget Metric Flanged Solid Bronze Bush 65x80x35mm (Allow 6-8 Weeks)

PBMF658035M1G1 Premier Budget Metric Flanged Solid Bronze Bush 65x80x35mm (Allow 6-8 Weeks)
$104.26 ex VAT
$104.26 ex VAT
Sale Sold out

Equivalent to: TBF 065/080 X 035

In stock

Price Break
9+ $69.84
19+ $65.91
29+ $65.13
39+ $64.34
49+ $63.56
69+ $62.77
99+ $58.85
199+ $58.07
249+ $57.28
499+ $56.50
999+ $54.93

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
65mm
Outside Diameter:
80mm
Length:
35mm
Technical
d 65mm
D 80mm
B 35mm
D1 90mm
B1 8mm
a 1.75mm
h 66.5mm
a Angle 124 deg
Tolerance shaft e7
Tolerance housing H7
Specific Dynamic Load Factor ( K ) 25 N/mm 2
Specific Static Load Factor ( K0 ) 45 N/mm 2
Permissable Sliding Velocity ( v ) min. 0 m/s
Permissable Sliding Velocity ( v ) max. 0.5 m/s
Coefficient of Friction ( y ) min. 0.08
Coefficient of Friction ( y ) max. 0.15
Weight 0.62kg
