• Drive-Flex PC14M-112S-90 - 14mm Pitch 112 Tooth Polychain and Synchrochain Cast Iron Taper Bore Timing Belt Pulley for 90mm Wide Belts
1 1

SKU: PC14M-112S-90-DRIVEFLEX

Drive-Flex PC14M-112S-90 - 14mm Pitch 112 Tooth Polychain and Synchrochain Cast Iron Taper Bore Timing Belt Pulley for 90mm Wide Belts

Drive-Flex PC14M-112S-90 - 14mm Pitch 112 Tooth Polychain and Synchrochain Cast Iron Taper Bore Timing Belt Pulley for 90mm Wide Belts
$1,069.63 ex VAT
$1,069.63 ex VAT
Sale Sold out

In stock

Price Break
3+ $764.77
5+ $724.52
9+ $684.27
19+ $644.02
49+ $627.92
74+ $611.82
99+ $531.31
199+ $0.00
249+ $0.00
499+ $0.00
999+ $0.00

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Drive-Flex - High Quality
Number of Teeth:
112
Pitch:
14mm
Item Type:
Taper Bore Pulley
Maximum Belt Width:
90mm
Technical
Material Cast Iron
No. teeth 112
Schematic Type 8
Bush no. 4535
Belt Width 90mm
Max. bore (metric) 125mm
Dp 499.11mm
De 496.31mm
Di 456mm
Dm 215mm
F 106mm
P 8mm
S 90mm
Weight Kg 49 kg
