• INA PCJ20-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 20mm Bore
  • INA
1 2

SKU: PCJ20-TV-FA125.5-INA

INA PCJ20-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 20mm Bore

INA PCJ20-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 20mm Bore
$58.58 ex VAT
$58.58 ex VAT
Sale Sold out

In stock

Price Break
4+ $39.24
9+ $37.04
19+ $36.59
29+ $36.15
39+ $35.71
49+ $35.27
59+ $33.07
69+ $32.63
79+ $32.19
89+ $31.74
99+ $30.86

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
20mm
Style:
PCJ
Bolt Hole Centres:
63.5mm
Technical
d 20mm
L 87mm
U 41.5mm
A 28mm
A1 13.4mm
A2 18mm
B1 31mm
d3 max 33mm
J 63.5mm
N 11mm
Q 1/4 - 28 UNF
V 63mm
Mass 0.33 kg
Basic dynamic load rating Cr 13600 N
Basic static load rating Cor 6600 N
Load carrying capacity of housing Cor G 10200 N
Designation of housing GEH.CJ04-TV
Designation of bearing GRAE20-NPP-B-FA107/125.5
Bearing end cap, closed design (supplied with end cap) KASK04-S-G
Bearing end cap, open design, with integral rotary shaft seal (available by agreement) KASK04-S-R-NBR
Back seal components RWDR04-R-NBR
