• INA PCJ25-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 25mm Bore
  • INA
1 2

SKU: PCJ25-TV-FA125.5-INA

INA PCJ25-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 25mm Bore

INA PCJ25-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 25mm Bore
$62.58 ex VAT
$62.58 ex VAT
Sale Sold out

In stock

Price Break
4+ $41.92
9+ $39.56
19+ $39.09
29+ $38.62
39+ $38.15
49+ $37.68
59+ $35.33
69+ $34.85
79+ $34.38
89+ $33.91
99+ $32.97

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
25mm
Style:
PCJ
Bolt Hole Centres:
70mm
Technical
d 25mm
L 95mm
U 40.5mm
A 28mm
A1 14.3mm
A2 17mm
B1 31mm
d3 max 37.5mm
J 70mm
N 11mm
Q 1/4 - 28 UNF
V 70mm
Mass 0.39 kg
Basic dynamic load rating Cr 14900 N
Basic static load rating Cor 7800 N
Load carrying capacity of housing Cor G 12100 N
Designation of housing GEH.CJ05-TV
Designation of bearing GRAE25-NPP-B-FA107/125.5
Bearing end cap, closed design (supplied with end cap) KASK05-S-G
Bearing end cap, open design, with integral rotary shaft seal (available by agreement) KASK05-S-R-NBR
Back seal components RWDR05-R-NBR
