• INA PCJ30XLNFA125 Four Bolt Cast Iron Square Housing with Eccentric Collar Insert and Anti-Corrosion Protection 30mm Bore
  • INA
1 2

SKU: PCJ30-XL-N-FA125-INA

INA PCJ30XLNFA125 Four Bolt Cast Iron Square Housing with Eccentric Collar Insert and Anti-Corrosion Protection 30mm Bore

INA PCJ30XLNFA125 Four Bolt Cast Iron Square Housing with Eccentric Collar Insert and Anti-Corrosion Protection 30mm Bore
$75.50 ex VAT
$75.50 ex VAT
Sale Sold out

In stock

Price Break
4+ $50.57
9+ $47.73
19+ $47.16
29+ $46.59
39+ $46.02
49+ $45.46
59+ $42.62
69+ $42.05
79+ $41.48
89+ $40.91
99+ $39.77

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
30mm
Style:
PCJ
Bolt Hole Centres:
82.5mm
Technical
d 30mm
L 108mm
U 46.8mm
A 29mm
A1 12mm
A2 20mm
B1 35.8mm
d3 max 44mm
J 82.5mm
N 11.5mm
Q M6
V 85mm
Mass 1.11 kg
Basic dynamic load rating Cr 20700 N
Basic static load rating Cor 11300 N
Designation of housing CJ06
Designation of bearing GRAE30-XL-NPP-B-FA125Bearing end cap, closed design (to be ordered separately)
KASK06 N/A
