• INA PCJ35-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 35mm Bore
  • INA
1 2

SKU: PCJ35-TV-FA125.5-INA

INA PCJ35-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 35mm Bore

INA PCJ35-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 35mm Bore
$87.38 ex VAT
$87.38 ex VAT
Sale Sold out

In stock

Price Break
4+ $58.53
9+ $55.24
19+ $54.58
29+ $53.92
39+ $53.27
49+ $52.61
59+ $49.32
69+ $48.66
79+ $48.00
89+ $47.35
99+ $46.03

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
35mm
Style:
PCJ
Bolt Hole Centres:
92mm
Technical
d 35mm
L 118mm
U 51mm
A 34.8mm
A1 15.5mm
A2 21.5mm
B1 39mm
d3 max 55mm
J 92mm
N 13mm
Q 1/4 - 28 UNF
V 90mm
Mass 0.79 kg
Basic dynamic load rating Cr 27500 N
Basic static load rating Cor 15300 N
Load carrying capacity of housing Cor G 18500 N
Designation of housing GEH.CJ07-TV
Designation of bearing GRAE35-NPP-B-FA107/125.5
Bearing end cap, closed design (supplied with end cap) KASK07-S-G
Bearing end cap, open design, with integral rotary shaft seal (available by agreement) KASK07-S-R-NBR
Back seal components RWDR07-R-NBR
