• INA PCJ40-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 40mm Bore
  • INA
1 2

SKU: PCJ40-TV-FA125.5-INA

INA PCJ40-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 40mm Bore

INA PCJ40-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 40mm Bore
$103.09 ex VAT
$103.09 ex VAT
Sale Sold out

In stock

Price Break
4+ $69.06
9+ $65.18
19+ $64.40
29+ $63.62
39+ $62.85
49+ $62.07
59+ $58.19
69+ $57.42
79+ $56.64
89+ $55.86
99+ $54.31

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
INA - High Quality
Inside Diameter:
40mm
Style:
PCJ
Bolt Hole Centres:
102mm
Technical
d 40mm
L 130mm
U 55.8mm
A 37.5mm
A1 17mm
A2 23mm
B1 43.8mm
d3 max 58mm
J 102mm
N 14mm
Q 1/4 - 28 UNF
V 99mm
Mass 1.05 kg
Basic dynamic load rating Cr 34500 N
Basic static load rating Cor 19800 N
Load carrying capacity of housing Cor G 19200 N
Designation of housing GEH.CJ08-TV
Designation of bearing GRAE40-NPP-B-FA107/125.5
Bearing end cap, closed design (supplied with end cap) KASK08-S-G
Bearing end cap, open design, with integral rotary shaft seal (available by agreement) KASK08-S-R-NBR
Back seal components RWDR08-R-NBR
